Sesame Roasting Machine U Model – MTSRU – 250
Sesame Roasting Process:
The sesame roasting process is one of the most important stages in the food industry, especially in tahini paste production. It plays a major role in developing the final product’s flavor, aroma, color, and overall quality. Roasting is not only a heating process but also a critical step that improves the commercial value and consistency of sesame-based products.
During roasting, sesame seeds are exposed to controlled heat to eliminate microorganisms and improve food safety. This process also enhances the seed’s internal structure, texture, and natural oil development. Proper roasting helps achieve the characteristic taste, aroma, and smooth texture required for premium tahini production while improving product stability and shelf life.
MarkoomTech Sesame Roasting Process:
The MarkoomTech U Model Sesame Roasting Machine is designed for efficient and controlled sesame roasting in industrial processing plants. The system operates using a traditional direct heating method combined with continuous mechanical mixing to ensure even heat distribution and consistent roasting performance across the entire batch.
One of the machine’s main advantages is its fully open-top U-shaped design. Unlike enclosed roasting systems, it allows steam and evaporated moisture to escape directly outside the chamber. This prevents humidity buildup inside the machine and maintains a dry roasting environment.
By reducing steam accumulation, the system improves heat transfer efficiency and shortens roasting time while preventing uneven roasting. This results in better color consistency, aroma formation, and flavor development. The U Shape Sesame Roasting Machine is widely recognized as a reliable and efficient solution for achieving premium roasting quality in industrial tahini and sesame processing applications.
Product Overview – U Model Sesame Roasting Machine:
The U Model Sesame Roasting Machine features an advanced U-shaped drum system mounted on a central shaft and heavy-duty gearbox for stable and continuous operation. It is equipped with stainless steel mixing arms that ensure constant agitation and uniform roasting performance.
The roasting drum is designed with a double-jacketed structure, incorporating steam inlet and outlet connections for controlled indirect heating. The insulated roasting chamber minimizes heat loss, improving overall energy efficiency and thermal stability.
An optional suction aspirator and extraction hood system can be integrated to manage steam and airflow during operation. The machine also includes a pneumatic discharge gate, enabling fast, controlled, and hygienic product unloading.
This batch-type roasting system is engineered for consistent and uniform roasting results, making it highly suitable for industrial sesame processing and premium tahini production lines.
The horizontal U-shaped design provides a large heat transfer surface, supporting efficient moisture reduction and uniform flavor development. Depending on the application, the system can operate using either direct or indirect heating, ensuring a stable golden-brown roasting profile for sesame seeds.
Main Components – U Model Sesame Roasting Machine
- U-Shaped Roasting Drum – Double-jacketed structure for uniform heat transfer
- Central Shaft & Gearbox – Heavy-duty drive system for stable rotation
- Mixing Arms (Stainless Steel) – Continuous agitation for uniform roasting
- Heating Jacket (Steam/Hot Oil Inlet & Outlet) – Indirect heating system for controlled temperature
- Insulated Chamber Body – Minimizes heat loss and improves energy efficiency
- Support Frame Structure – Reinforced base for industrial stability
- Pneumatic Discharge Gate – Fast and hygienic product unloading system
- Drive Motor System – High-torque motor for continuous operation
- Suction Hood (Optional) – Steam and vapor extraction system
- Control Panel (Optional PLC) – Temperature and process control interface
Process Description – U Model Sesame Roasting Machine:
Dehulled, washed, and dried sesame seeds are loaded into the U-shaped roasting drum, where they are exposed to the heated surface of the insulated double-jacket chamber.
Continuous stainless steel mixing arms provide uniform agitation, ensuring consistent heat distribution throughout the batch and preventing localized overheating.
The system operates as a controlled batch roasting process, allowing precise adjustment of time and temperature to achieve uniform color development, aroma formation, and texture consistency.
After completion of the roasting cycle, the sesame seeds are discharged with consistent quality, making them suitable for industrial tahini production applications.
This controlled roasting method enhances flavor development, preserves natural oil content, and ensures stable, high-quality output for large-scale sesame processing and tahini manufacturing plants.
Related Sesame Processing Machines:
MarkoomTech provides a complete range of industrial sesame roasting solutions designed for different production capacities and processing requirements:
- Sesame Roasting Machine Market Model – MTSR-50
- Sesame Roasting Machine U Model – MTSRU-250
- Sesame Roasting Machine Batch Model – MTSR-250
- Horizontal Roasting Machine – Cylinder Model – MTHRC-1700
MarkoomTech sesame roasting machines – Sesame Roasting Machine Market Model – MTSR-50, Sesame Roasting Machine Batch Model – MTSR-250, Sesame Roasting Machine U Model – MTSRU-250, and Horizontal Roasting Machine – Cylinder Model – MTHRC-1700 – are designed for all types of sesame roasting applications. They are engineered for efficient operation, uniform roasting performance, and easy integration into industrial sesame processing lines.
Contact MarkoomTech today for technical consultation, pricing details, and complete production line solutions tailored to your requirements.
